High Performance Reliable Raytools Laser Cutting Head for Fiber Laser Cutting Machines
To help customers better understand different laser head structures and applications, Xianming Laser provides a clear overview of common Raytools models used in fiber laser cutting machines. With stable optical performance and advanced laser technology, Raytools laser heads are widely applied in modern fiber laser equipment from low- to ultra-high-power metal cutting.
BM Automatic Series
BM110 (3kW)
High-performance auto-focus cutting head with optimized optical design for improved cutting quality.
Large auto-focus range (–12 to +10 mm) with 0.05 mm precision, reducing manual adjustment.
Equipped with protective lenses and a drawer-type lens mount for easy replacement and simple maintenance.
Supports multiple interfaces such as QBH and QD, compatible with mainstream laser sources.
BM111 (4kW)
Triple protective lenses provide enhanced protection for collimation and focus lenses.
Fast auto-focus speed (170 mm/s) with 0.05 mm accuracy.
IP65 high-level dustproof design for improved stability.
High cutting speed: up to 0.7 m/min on 12 mm stainless steel using a 3000W laser.
BM06K (6kW)
High-efficiency cooling structure for collimation lens, focus lens, and nozzle, suitable for long-term continuous operation.
Four protective lenses reduce contamination and extend lens life.
Collimation-focus adjustment for faster and wider focus range.
Built-in temperature monitoring with APP/PC viewing and a multi-layer optical protection system.
BS Intelligent Series
BS03K-CAT (4kW)
Three protective lens groups with optimized optical and airflow design, increasing air-cutting speed by 10%–40%.
Simplified maintenance with anti-collision structure to minimize damage risks.
Standard air pressure and protective lens temperature monitoring with one-click intelligent air-pressure calibration.
Fast focusing and support for small-nozzle full-power carbon steel cutting.
BS06K-CAT (6kW/8kW)
Four-layer optical protection with high sealing capability.
Supports analog, pulse, and EtherCAT bus control for more flexible focusing.
Anti-corrosion design with optimized water-cooling structure for longer service life.
Comes standard with air pressure and temperature monitoring and supports built-in capacitive amplifier.
BS12K-CAT (12kW)
Four sets of protective lenses combined with a high-seal core structure.
Water-cooled nozzle design ensures stable thick-plate cutting and improved surface quality.
Supports piercing detection and real-time cutting process monitoring, compatible with Raytools CNC systems.
BS20K / 30K / 40K-CAT (20kW–40kW)
Designed for high-power cutting scenarios with four-layer protection, strong water cooling, and intelligent monitoring functions.
Supports bus-control fast focusing, ideal for thick-plate, mass-production, and high-intensity industrial cutting.
Equipped with standard air pressure, temperature, and stray-light monitoring for enhanced safety and stability.
Summary
BM Series:
Best for medium-power machining, featuring simple structure, easy maintenance, and high cost-performance.
BM06K:
Offers higher power and stronger cooling capability, suitable for long-term continuous operation.
BS Series:
Covers 4kW to 40kW, fully equipped with intelligent monitoring and bus-control focusing, ideal for high-efficiency, thick-plate, and industrialized production environments.
As metal processing demands continue to grow, a stable and intelligent cutting head has become essential for improving cutting quality and efficiency. Raytools laser heads stand out in Xianming Laser machines with their mature auto-focusing technology, strong optical protection, and flexible interface compatibility. Moving forward, Xianming Laser will keep working with trusted supply partners to deliver efficient and precise laser solutions for global customers, helping businesses boost productivity and competitiveness.
